On the CGI-3D-model-configuratorreturn page, select the desired ratio, motor manufacturer and model and the configurator will output the appropriate data.
CGI Motion, a manufacturer of custom precision gearboxes, precision assemblies and mechanical sub-assemblies, announced its latest and newly updated 2D and 3D CAD model library that now supports CGI gearbox matching with motors from top manufacturers.
Simply choose the CGI gearbox for your application or current product in use. On the CGI-3D-model-configuratorreturn page, select the desired ratio, motor manufacturer and model and the configurator will output the appropriate data. Values include Pilot diameter data, bolt circle data, mount hole, shaft diameter and length. 3D or 2D CAD data for virtually any CAD package can be generated as well as PDF files for download.
Easily generate a request for quote directly from the page or contact CGI for customer-service engineers.
CGI Motion
www.cgimotion.com
